Das META POWER SX AVINOX vereint Kraft, Dynamik und Wendigkeit. Es richtet sich an alle, die lange fahren möchten mit einem kraftvollen und drehmomentstarken Motor. Seine Federung entwickelt 160mm Federweg über unser Virtual Contact System. Dank seines geringen Gewichts und eines 27,5''-Hinterrads zeigt es sich reaktionsschnell und besonders agil.
Technische Daten
Rahmen
META POWER SX AVINOX, 160 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6
Motor
AVINOX M2S
150 Nm peak torque with a 1,300 W boost mode, and 130 Nm / 1300 W in normal operation
Akku
AVINOX
600 Wh on S, 800 Wh on M / L / XL, Fully integrated main battery
AVINOX 508w Fast Battery charger
Display
AVINOX DP100 : Integrated and colored touchscreen providing a large range of information : speed, ride mode, battery range, charge level, fitness data, elevation gain, altitude and many more. It also features a USB-C port, GPS sensor, barometer, compass, 4G connection and even a theft alarm system.
Switch: AVINOX BC100, Wireless controller.
Dämpfer
FOX Float X Performance
230 x 60 mm, 2-postion (open/firm) lever, LSR, 0.4ci Spacers
Gabel
FOX 36 Performance 160 mm
29", Grip damper, LSR, Boost (15 x 110 mm), 44 mm offset
Steuersatz
- ACROS ZS56 / ZS66
- Alloy cups, stainless steel & sealed bearings
Vorbau
RIDE ALPHA 40 - 40 mm extension, 31.8 mm
Lenker
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Griffe
RIDE ALPHA MUSHROOM
Soft compound, single clamp, black
Bremsen
TRP DH-R EVO PRO, 4 pistons
Rotors: TRP RS06E, 6-bolt, 220 mm front / 203 mm rear
Schaltung
SRAM Eagle 90 12s
Kettenführung
- RIDE ALPHA
- 32t-34t
Schaltwerk
SRAM Eagle 90
12s, T-TYPE
Kurbeln
E13 HELIX CORE, 155 mm crank arms
Chainring: SRAM CR T-TYPE, 34t, BCD 104
Kette
SRAM GX EAGLE T-TYPE
12s, Flat Top
Kassette
SRAM XS 1270 T-TYPE
12s, 10-52t
Felgen
DT SWISS H 1900
Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
Naben
DT SWISS 370 Hybrid
Rear: 28h, sealed bearings, 12 x 148 mm, Hyperglide - Front: 28h, sealed bearings, 15 x 110 mm
Speichen / nippel
DT SWISS Hybrid 1
Straightpull, 2.34/2.0mm, double butted, stainless, with ProLock, black
Reifen
Rear: MAXXIS MINION DHRII 27.5'' - Front: MAXXIS MINION DHRII 29'
Rear: 27.5x2.50WT 3C MaxxTerra / EXO+ Casing / TR - Front: 29x2.50WT 3C MaxxTerra / EXO+ Casing / TR
Sattelstütze
KS Ragei
34.9 mm, 150 mm on S, 175 mm on M and 190 mm on L/XL
Sattel
WTB SOLANO 142 x 240 mm, Medium
Gewicht
24,65 kg / 54.3 lbs
Minimum weight for M size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Inklusive pedale
- CRANKBROTHERS Stamp 1
Farbe
Pure White - Shiny Finish
Zubehör
- RideWrap Lotus Pro™ protection film applied, motor protector, chain stay protector, seat stay protector, fork fender, FIDLOCK base.
